Automatic Non Woven Fabric Slittling Machine

Company Name: SEEK WINWIN
Effective Width: 1600- 3200MM
Max Mechanical Speed: 2000M/Min
Computerized: Yes
Sales Mode: Factory Outlet
Model:SW-SLITTER
Brand:SEEK WINWIN
Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

  • SW-SLITTER

  • SEEK WINWIN

High Speed Spunbond Nonwoven Fabric Slitting Machine

PRODUCTS DESCRIPTION



461235


QUICK DETAIL


The non-woven slitting machine is a kind of equipment for trimming and slitting wide-width materials according to different needs in the production process.


ITEM NO.
EFFECTIVE WIDTHGSMMax Speed
SW-SLITTER
1600-3200MM9-1502000m/min

 Equipment Parameters

Design Speed: 2000m/min

Max roller dia.: 2500mm

Max winding roller dia.: 1200mm

Mix slitting fabric: 80mm

Change roller mode: Automatic

Rolling diameter measuring: support

Rewinding shaft position feedback: support

OUR SERVICE


contuct me

Turnkey Project

Inquiry and consulting support

Latest industry trends

Follow up and show the process at all times




Packing&Delivery

Packing & Delivery

Packing:

As per export standard, they will also be treated before delivery against damage and rusting.

Container:

1.6SMS ----8x40'HQ ;

1.6SSMS---11x40'HQ ;

1.6SMMS----9x40'HQ ;

2.4SMS ----10x40'HQ ;

2.4SSMS---15x40'HQ ;

2.4SMMS----11x40'HQ ;

3.2SMS ----14x40'HQ ;

3.2SSMS---20x40'HQ ;

3.2SMMS----16x40'HQ ;

After-Sale Service

After-Sale Service

One year warranty

English Manual, Electric Diagram

Training how to install the machine,

Training how to use the machine

Engineers available to service machinery oversea





INDUSTRY APPLICATION


The non-woven slitting machine is mainly used to slit wide and wide rolls into various narrow rolls suitable for production needs. The slitting process includes two processes: unwinding and winding.

The tension control of the unwinding and rewinding materials is the key link of the slitting machine. The non-woven fabric slitting is based on the original electronic control system and adds automatic edge-to-edge control, which achieves the desired effect, improves the working performance of the machine, and makes the machine more stable and durable in high-speed operation.
